Chassis & Cover:
Non-ferrous alloy
End caps: Metal
Doors:
- 1-3/4" (44.45 mm) thick,
- 3-3/4" for single doors, wood or hollow metal
- 3-1/2" (88.90 mm) minimum stile for double doors
Handing: Reversible
Dogging:
Allen-type key standard, cylinder available.
Top/Bottom Bolts/Latchbolt:
Brass 1/2" (12.7 mm) throw top, 3/4" (19.05 mm) bottom
Throughbolts: Order separately
Rail Assembly: Steel
Rail Size:
- F Rail furnished standard for doors up to 36", can be cut down to accommodate 32" doors.
- E Rail for doors up to 32", can be cut down to accommodate 24" doors.
- G Rails for doors up to 48", can be cut to accommodate 36" doors.
Rods:
90"–extension kits available
Finishes:
AL, BRZ, Powder Coat, LBZ, (sprayed finishes). |
